HR Wheel Hay Rake
Finger wheel Hay Rake,used to collect the cut grass|stalk|straw together and put these in a standard line for tractors with PTO 540 rpm
online service
Finger wheel Hay Rake
1. easily adaptable to each type of tractor by its three point linkage system
2. used for separating the green materials over the field to ventilate them to dry in a short time.
3. used to collect the cut grass|stalk|straw together and put these in a standard line
4. better for large field and large baler
PARAMETER DATA
1. easily adaptable to each type of tractor by its three point linkage system
2. used for separating the green materials over the field to ventilate them to dry in a short time.
3. used to collect the cut grass|stalk|straw together and put these in a standard line
4. better for large field and large baler
PARAMETER DATA
| Model | HR-3 | HR-4 | HR-5 |
| Weight kgs | 150 | 295 | 345 |
| Working speed km/h | 5-10 | 5-10 | 5-10 |
| Productivity ha/h | 1 | 1.5~3.5 | 3~5 |
| Matched power HP | 15/20 | 20/27 | 40/55 |
| Working width m | 3 | 4 | 4.8 |
| NO.of wheels | 4 | 6 | 8 |
| Disc diameter m | 1.46 | 1.46 | 1.46 |
| No.of tines/ pcs | 40 | 40 | 40 |
| grass width m | 1~1.5 | 1~1.5 | 1~1.5 |
| Mounted type | three point mounted | ||
