Sweet Potato Harvester
Sweet Potato Harvester,such as harvesting,excavating ,choosing,the series include the middle drive transmission and the left-side drive transmission for different types of tractors
online service
4U Series Potato Harvester has the merits of high efficiency, lower breakage, running fast without trembling, and no blocking by the grasses. Moreover, the structure is simple and the operation life time is long, etc.
| Model | 4U-1 | 4U-1A | 4UZ-1 | 4U-2 | 4U-3 |
| Rows | 1 | 1 | 1 | 2 | 2 |
| Row space(cm) | 55-80 | 55-80 | 55-80 | 55-80 | |
| Productivity(mu/h) | 3-5 | 3-5 | 3-5 | 5-8 | 8-15 |
| Total weight(kg) | 180 | 100 | 160 | 700 | 1200 |
| Matched power(hp) | 22-35 | 8-15 | 22-35 | 50-80 | 70-120 |
| Working depth(cm) | 25 | 20 | 25 | 25 | 25 |
| Working width(m) | 0.65 | 0.53 | 0.65 | 1.65 | 1.65 |
| Gain rate (%) | ≥96 | ||||
| Loss rate (%) | ≤2 | ||||
| Export rotary speed(RPM) | 560/1250 | 1000 | 560/1250 | 560 | 560 |
| Overall dimension(cm) | 240*90*90 | 120*100*75 | 280*220*100 | 330*390*310 | |
