20HP Walking Tractor
High-power tractor 20hp walking tractor Trailer, rotary tiller,single plough,disc plough,Air cooling diesel 20hp power tiller,1-cylinder, 4stroke, horizontal, hopper water by diesel condenser
online service
Specifications of the 2013 hot sale 20hp walking tractor
The tractor is featured by its simple and compact construction , reliability , long service life ,easy operation , ample output , light weight and high versatility This tractor is very suitable for use in paddy field , small dry field , orchards , vegetable gardens of hilly land with small inclination . It can be used for ploughing , rotary cultivating , harrowing in paddy field , harvesting , transportation ,etc .if suitable implements or accessories are attached . In addition , the tractor can be extensively used as a stationary power station for small scale drainage and irrigation , spraying , grain threshing , cottons ginning , flour milling , fodder cutting , etc.
The tractor is featured by its simple and compact construction , reliability , long service life ,easy operation , ample output , light weight and high versatility This tractor is very suitable for use in paddy field , small dry field , orchards , vegetable gardens of hilly land with small inclination . It can be used for ploughing , rotary cultivating , harrowing in paddy field , harvesting , transportation ,etc .if suitable implements or accessories are attached . In addition , the tractor can be extensively used as a stationary power station for small scale drainage and irrigation , spraying , grain threshing , cottons ginning , flour milling , fodder cutting , etc.
| Model | DF-20 | DF-20L | |
| Diesel engine | ZH/ZS 1110 | ZH/ZS 1110NL | |
| Type | 1-cylinder, 4stroke, horizontal, hopper water cooled diesel | 1-cylinder, 4stroke, horizontal, hopper water by diesel condenser | |
| Rated power (kW/hp) | 14.70 / 20 | ||
| Rated speed (rpm) | 2200 | ||
| Cooled system | Evaporative | Radiator | |
|
Overall dimension (LXWXH) (mm) |
2680x 960x1250 | ||
| Wheel tread (mm) | 800, 740 , 640 , 580 | ||
| Tyre | 6.00 - 12 | ||
| Ground clearance (mm) | 182 | ||
| Clutch type | Two-disc, constant-contact, friction | ||
| Construction weight (kg) | 350 | ||
| Forward (km/hr) | 1.54 2.75 4.51 5.83 10.34 16.83 | ||
| Reverse (km/hr) | 1.20 4.18 | ||
| Optional implement |
1. 1LS-220C Two share plough 9. 1LYQ-320 Three disc plough 2. 1LS-220Y Two disc plough 10.1LYQ-420 Four disc plough 3. 7C-1.5 Trailer 11. 2BG-5A Rotary seed drill 4. 65BP-55 Water pump 12. 2BG-6A Rotary seed drill 5. 4GL-120 Reaper 13. 100-640 Anti-skid iron wheel 6. 4GL-150 Reaper 7. 1KS-30 Ditching machine 8. PY series Sprinkler About the detail of implement , please visit our website:www.daxili.com |
||
