Slasher(Topping Mower)
SL Series Rear Mounted Grass Slasher/Mower,Mower slasher matched with 20-50HP,With steering wheel,Working width from 110-180cm,CE,PTO driven
online service
|
Model
|
DS3FT6
|
DS4FT
|
DS4FT6
|
|
Dimensions (L * W * H)
|
1170x1070x980mm
|
1320x1220x980mm
|
1472x1372x980
|
|
Weight
|
150kg
|
170kg
|
190kg
|
|
Working width
|
1030mm
|
1180mm
|
1332mm
|
|
Work efficiency
|
3000-8200㎡/h
|
3500-9500㎡/h
|
4000-10000㎡/h
|
|
PTO speed
|
540r/min
|
540r/min
|
540r/min
|
|
PTO flower key
|
6x8x1000mm
|
6x8x1000mm
|
6x8x1000mm
|
|
Motive power
|
20-30hp
|
20-35hp
|
20-35hp
|
|
|
|||
|
Model
|
DS5FT
|
DS6FT
|
DS7FT
|
|
Dimensions (L * W * H)
|
1624x1524x980mm
|
1929x1829x980mm
|
2234x2134x980mm
|
|
Weight
|
220kg
|
240kg
|
260kg
|
|
Working width
|
1484mm
|
1789mm
|
2094mm
|
|
Work efficiency
|
4400-12000㎡/h
|
5300-14000㎡/h
|
6200-16700㎡/h
|
|
PTO speed
|
540r/min
|
540r/min
|
540r/min
|
|
PTO flower key
|
6x8x1000mm
|
6x8x1200mm
|
6x8x1200mm
|
|
Motive power
|
25-40hp
|
40-70hp
|
60-100hp
|
