3PT Snow Blower
Snow blower is developed to meet the consumers continuously increasing demands of quality, design and appealing prices.
online service
Frontal snow blower with hydraulic system front end loader hitch
Snow Blade for Tractor, snow blower,snow shovel, snow thrower,snow plow, snow remover,snow cleaner, snow plough,snow pusher,
| THE MAIN TECHNICAL SPECIFICATIONS | ||||||
| MODEL | 518FRT | 518PTO | 618FRT | 618PTO | 718FRT | 818FRT |
| Cuting Width | 54" | 54" | 66" | 66" | 70" | 84" |
| Cuting Height | 24" | 24" | 24" | 24" | 24” | 24" |
| Fan No. | 4 blades | 4 blades | 4 blades | 4 blades | 4 blades | 4 blades |
| Fan Diameter | 18" | 18" | 18" | 18" | 18" | 18" |
| Auger Diameter | 4.8" | 4.8" | 4.8" | 4.8" | 4.8" | 4.8" |
| Drive Fan | Hyd w/gearbox | Hyd w/gearbox | Hyd w/gearbox | Hyd w/gearbox | Hyd w/gearbox | Hyd w/gearbox |
| Drive auger | Gearbox w/chain | Gearbox w/chain | Gearbox w/chain | Gearbox w/chain | Gearbox w/chain | Gearbox w/chain |
| Hitch Type | Front end loader | 3-point Cat,1or 2 | Front end loader | 3-point Cat,1or 2 | Front end loader | skid steer |
| Hitch adjustment | FEL quickly move LD PIN | 3 position | FEL quickly move LD PIN | 3 position | FEL quickly move LD PIN | FEL quickly move LD PIN |
| Chute Deflector | Handing/4position/115°-145° | Handing/4position/115°-145° | Handing/4position/115°-145° | Handing/4position/115°-145° | Handing/4position/115°-145° | Handing/4position/115°-145° |
| Cutting Edge | 3/8”X4”Beveled | 3/8”X4”Beveled | 3/8”X4”Beveled | 3/8”X4”Beveled | 3/8”X4”Beveled | 3/8”X4”Beveled |
| Skid Shoes | Cut type adjustable | Cut type adjustable | Cut type adjustable | Cut type adjustable | Cut type adjustable | Cut type adjustable |
| System controls&drive | Hyd.Loader sensing block flow | PTO w/shear pin | Hyd.Loader sensing block flow | PTO w/shear pin | Hyd.Loader sensing block flow | Hyd.Loader sensing block flow |
| Hyd.Requirement | 6.6-13.2gpm 2000psi min | NO | 6.6-13.7gpm 2000psi min | NO | 6.6-13.7gpm 2000psi min | |
| Tractor HP | 25-35HP | 25-35HP | 25-55HP | 25-55HP | 45-65HP | 50-75hp |
| Approx. Weight | 700lbs | 700lbs | 800lbs | 800lbs | 890lbs | 980lbs |
