3PT Hay Baler
Round Hay Baler / Square Hay Baler, PTO driven square hay bale, 500mmdia.*700mm,or 610mmdia.*700mm ,PTO transmition, 18-50hp tractor
online service
This machine with advanced design and structure, processing high quality round bales. CE certificate was passed in 2011.
It is consist of main machine, pickup part, compress rolls, automatic binding hay bales, hydraulic pressure ejection system, three point linkage etc. It can move and work with a 15-90hp tractor by PTO shaft.
The whole working program is successive, accurate and reliable, the bundled round grass bales compact outside and loose inside and has good air permeability.-
The machine is suitable for baling of hay, grass, wheat, silage, alfalfa and other materials suac as straw etc.
It can resist wind, rain and snow under open storage and is convenient for long-term storage and long distance transportation. this is a great sighificance to the prompt harverst of pasture in agricultural and pastoral areas, the effictive use of crop stalks as well as the disaster countering and livestock protection.
It is consist of main machine, pickup part, compress rolls, automatic binding hay bales, hydraulic pressure ejection system, three point linkage etc. It can move and work with a 15-90hp tractor by PTO shaft.
The whole working program is successive, accurate and reliable, the bundled round grass bales compact outside and loose inside and has good air permeability.-
The machine is suitable for baling of hay, grass, wheat, silage, alfalfa and other materials suac as straw etc.
It can resist wind, rain and snow under open storage and is convenient for long-term storage and long distance transportation. this is a great sighificance to the prompt harverst of pasture in agricultural and pastoral areas, the effictive use of crop stalks as well as the disaster countering and livestock protection.
| Model | 0850 | 0870 |
| Bale size: dia.*width | φ50×70cm | φ61×70cm |
| Dimension (L*W*H) | 115*130*120cm | 130*130*135cm |
| Weight | 425kg | 465kg |
| Pickup width | 800mm | 800mm |
| Efficiency | 3-6km/hour | 3-6km/hour |
| Capacity (bales per hour) | 100-140 bales/hour | 100-120 bales/hour |
| Tire | 4.0-8.0 or 16x6.5-8-4PR | 4.0-8.0 or 16x6.5-8-4PR |
| Match power | 15-90hp tractor | 15-90hp tractor |
| PTO speed | 540 rpm | 540 rpm |
| Safety alarm signal | have | |
| Light signal | have | |
| Auto twine binding system | have | |
| Hydraulic ejection system | have | |
