FFC Disc Mill
FFC Disc Mill TYPE FFC-45 FFC-37 FFC-23 FFC-15 Rotational speed of main shaft r.p.m 3000 3600 5800 9000 Outer diameter of the rotator (including oblate gear) mm 450 370 230 150 Number of oblate gears of the rotator p.c. 5 4 4 3 Number of knuckle gears
online service
This disk mill is designed compactly with a wonderful appearance: It is small in size and light in weight, reliable in operation and easy in maintenance. It has a large range of service and proves to be of high quality in crushing. In one word, this mill will provide the best service to the users. Apart from the above-mentioned application, they can also be used for the rapid beating of paper pulp, reduction of chemical materials and wet grinding f watery food stuffs, such as fresh fruits, fresh sweet potato, wet Soya bean, etc. Efficiency, is good and they are always free from being clogged.
| TYPE | FFC-45 | FFC-37 | FFC-23 | FFC-15 | |
| Rotational speed of main shaft | r.p.m | 3000 | 3600 | 5800 | 9000 |
| Outer diameter of the rotator (including oblate gear) | mm | 450 | 370 | 230 | 150 |
| Number of oblate gears of the rotator | p.c. | 5 | 4 | 4 | 3 |
| Number of knuckle gears of the rotator | p.c. | 12 | 8 | 8 | 3 |
| Circles of square gears of the gear wheel | circles | 2 | 2 | 2 | 2 |
| Pitch between Oblate gear & Screen | mm | 16.5 | 16.5 | 19 | 9 |
| Sieve Size | mm |
3.6 1.2-0.6 |
3.6 1.2-0.6 |
3.6 1.2-0.6 |
1.2 0.6 |
| Dimension(length*width*height) | mm | 1180X740X745 | 1100X660X650 | 650X675X515 | 630X310X345 |
| Elector Motor | kw | 11 | 7.5 | 3 | 1.1 |
| Weight, | kg | 210 | 155 | 65 | 16.5 |
