WC-40DH Wood Chipper
WC-40DH-wood-chippe Wood Chipper Shredder
online service
Usage:
1. The small chips made by the wood chipper can be used for animal bedding, for the forestry and
soil protecting, for new energy making, for compost and for charcoal.
2. Some customers use their colored garden waste chips, cover the soil and made the garden
beautiful; some of them use the garden waste chips in the fireplace.
Technical specification of diesel engine wood chipper:
1. The small chips made by the wood chipper can be used for animal bedding, for the forestry and
soil protecting, for new energy making, for compost and for charcoal.
2. Some customers use their colored garden waste chips, cover the soil and made the garden
beautiful; some of them use the garden waste chips in the fireplace.
Technical specification of diesel engine wood chipper:
| Model | DH-18/DH-22 | DH-30/DH-40 |
| Power | 18hp/22hp | 30/40hp |
| Engine | one cylinders Electric started diesel engine | 3cylinders Electric started diesel engine |
| Chipper capacity | 8”diameter/200mm | 8" diameter/200mm |
| Feeding system | Mechanical / hydraulic | Hydraulic |
| Rotor plate size | 640mm | 760mm |
| Rotor plate weight | 85kg | 85kg |
| Knives number | 1stationary knife:2rotor knives | 1stationary knife:2rotor knives |
| Blade Material | Durable Chromium CR-12 | Durable Chromium CR-12 |
| Dimensions(Hopper discharge) | 1300x1400x1100mm | 1900x1300x2500mm |
| Feed Hopper inner Opening | 200x220mm | 500mmx500mm |
| Discharge Hood Height | 1800mm | 2000mm |
| Rated RPM | 1080 | 1280 |
| Discharge hood rotates | 360 degree | 360 degree |
| Settings | turning lights, easy discharge hood,2”Ball Hitch, Safety Chains and leaf spring on axle | |
| Gross Weight | 680kg/720kg | 780kg(1720LBS) |
| Working efficiency | 6-10CBM/H | 10-12CBM/H |
