Silent Diesel Generator

diesel generator
1) Engine models: 495(Z)D, R4105(Z)D, R6105(Z)(AZL)D, 6113ZLD,6126ZLD.
2) Alternator: Stamford, Marathor

Powerful Silent Generator Set 10KW-200KW Feature:

1) Output range: from 10kW up to 200 kW
2) Engine models: 495(Z)D, R4105(Z)D, R6105(Z)(AZL)D, 6113ZLD,6126ZLD.
3) Alternator: Stamford, Marathon, Leroy Somer and Chinese brand with brushless
    and "H" Class Insulation.
4) Water-cooled
5) 8hrs operation base tank
6) Key start / auto start
7) Sound-proof / weather-proof canopy is optional
8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wires
    alternating current output
9) Frequency: <3%
10) Frequency at stable state: <0.5%
11) Frequency deviation at instantaneous state: ≤+10%
12) Frequency return time: ≤3s
13) Voltage deviation at stable state: ≤±1%
14) Voltage deviation at instantaneous state: ≤+20%
15) Voltage return time: ≤4s
16) Voltage modulation: ≤0.3%
17) Standard configuration of gen sets:
      a) Engine: Ricardo series diesel engine
      b) Engine type: water-cooled, in line four-stoke, Humit cylinde liner,
          direct injection
      c) Alternator: brushless alternator
18) Control system:
      a) Automatic alarm system: the unit has the acousto-optics alarm
          system and arrestor for any situation as the start defeat, the water
          is over temperature, the oil pulls down, over speed, over load and
          over current
      b) Operation display:
          i) Unit voltage, tri-phase load current and frequency display
          ii) Water temperature, oil pressure display
          iii) Fuel level, fuel temperature display
          iv) Audible and visual alarm lamps and buzzers
19) Starting system: DC alternator is used to start engine
20) Short circuit protection: MCCB air switch
21) Cooling system: combined cooling water tank fitted to meet the
      requirement of radiation at ambient temperature 40°C
22) Filter system: oil, fuel and air filter
23) Accessories: exhaust elbow, bellow, muffler
24) Supply standard collocation:
      a) Diesel engine with all accessories, 3 filter, electric systems
      b) Alternator
      c) Steel structure
      d) Fan and water tank cooling system
      e) Flange connector
      f) 12 / 24V starting motor and charge engine
      g) Air cleaner, fuel cleaner, oil cleaner
      h) On-board control panel
      i) MCCB air conservation switch
      j) 12 / 24V starting accumulator and Battery line
      k) Set shock absorber
      l) High-efficient silencer
