Single Cylinder Diesel Engine
single cylinder 4 stroke diesel engine , Single cylinder, horizontal, 4-strokes, water-cooled,Prechamber
online service
single cylinder 4 stroke diesel engine
The main technical parameters of the engine
Technical parameters
The main technical parameters of the engine
| Item | Model | Rated power kw | Rated speed r/min | Fuel Consumption（g/rw.h） | |
| 150 | LD1100 | 11 | 2200 | one cylinder, horizontal, four-stroke, direct injection | ≤262.5 |
| ZS1100 | 11 | ≤238 | |||
| S1100 | 11.03 | ≤246.2 | |||
| 170 | LD1105 | 12.1 | ≤238 | ||
| ZS1105 | 12.1 | ≤238 | |||
| ZH1105 | 13.13 | ≤247.5 | |||
| SD1105 | 12.1 | ≤250.2 | |||
| 180 | LD1110 | 13.2 | ≤242 | ||
| ZS1110 | 13.2 | ≤238 | |||
| ZH1110 | 13.24 | ≤244.8 | |||
| SD1110 | 13.2 |
≤250.2 |
|||
|
200 |
LD1115 | 14.7 | ≤242 | ||
| ZS1115 | 14.7 | ≤238 | |||
| ZH1115 | 14.71 | ≤242.1 | |||
| LC1115 | 14.7 | ≤250.2 | |||
| TC1115 | 14.7 | ≤250.2 | |||
|
220 |
KM130 | 16.2 | ≤242 | ||
| LD24 | 15.44 | ≤242 | |||
| JD118 | 15.44 | ≤242.1 | |||
| LC130 | 16.2 | ≤250.2 | |||
| JL128 | 16.2 | ≤250.2 | |||
|
240 |
KM138 | 17.6 | ≤242 | ||
| LC138 | 17.6 | ≤250.2 | |||
| LC24 | 17 | ≤250.2 | |||
|
260 |
LD28 | 18.38 | ≤252 | ||
| KM160 | 19.12 | ≤242 | |||
| LC26 | 18.38 | ≤250.2 | |||
| LC28 | 19.12 | ≤250.2 | |||
| ZH1125E | 18.38 | ≤240.7 | |||
| 280 | LC30 | 20.58 | ≤250.2 | ||
| 300 | KM173 | 22.06 | ≤242 |
Technical parameters
| Model | R175 | R180 | R175ANL | R180NL |
| Type | Single cylinder, horizontal, 4-strokes, water-cooled,Prechamber | |||
| Max power(hp) | 6.6 | 7.7 | 6.6 | 7.7 |
| Displacement(L) | 0.353 | 0.402 | 0.353 | 0.402 |
| Fuel consumption rate (g/kw.h) | ≤289.2 | ≤278.8 | ≤289.2 | ≤278.8 |
| Starting System | Hand cranking | |||
| Weight(N/G) (KGS) | 65/75 | 70/80 | 65/75 | 70/80 |
| Packing Dimension(mm) | 600*380*570 | 620*380*570 | 600*380*570 | 620*380*570 |
| Loading Capacity | 216/20'GP | |||
