Walking Tractor Implements
Walking Tractor 8hp,10hp,12hp,15hp,18hp,20hp walking tractor, and other implements like trailer,rotary tiller,seeder,single plough,double plough etc
online service
We can also supply 8hp,10hp,12hp,15hp,18hp walking tractor and other implements like trailer,rotary tiller,seeder,single plough,double plough etc.
Brief Introduction & Advantage
151 WalkingTractor features the following advantages:
1. 15 HP Direct Injection type diesel with double bearing system for the crankshaft, it is easy for the starting and fuel save.
2. Special designed heavy type gearbox assembly, strengthen gears, shaft and gearbox housing, which make it could bear the more heavy work.
3. Big tilling width rotary tiller:800 to 1000mm..
4. Dual-function type that can be used as a means of traction as well as drive.
5. It is featured by its simple and compact structure, good reliability, long service life, easy operation, ample output, light weight and good cross-country ability.
6. It is very suitable for use in paddy fields, dry fields, orchards, vegetable gardens and hilly land with a little inclination.
7. It can be used for plough, rotary tilling, harrowing in paddy fields, harvesting, drilling, ditching, transportation and etc., if suitable farm implements or accessories are attached.
8. In addition, it can also be extensively used as a stationery power source for small scale drainage and irrigation, sprinkling, grain threshing, cotton ginning, flour milling, fodder cutting and so on.
Specifications:
Brief Introduction & Advantage
151 WalkingTractor features the following advantages:
1. 15 HP Direct Injection type diesel with double bearing system for the crankshaft, it is easy for the starting and fuel save.
2. Special designed heavy type gearbox assembly, strengthen gears, shaft and gearbox housing, which make it could bear the more heavy work.
3. Big tilling width rotary tiller:800 to 1000mm..
4. Dual-function type that can be used as a means of traction as well as drive.
5. It is featured by its simple and compact structure, good reliability, long service life, easy operation, ample output, light weight and good cross-country ability.
6. It is very suitable for use in paddy fields, dry fields, orchards, vegetable gardens and hilly land with a little inclination.
7. It can be used for plough, rotary tilling, harrowing in paddy fields, harvesting, drilling, ditching, transportation and etc., if suitable farm implements or accessories are attached.
8. In addition, it can also be extensively used as a stationery power source for small scale drainage and irrigation, sprinkling, grain threshing, cotton ginning, flour milling, fodder cutting and so on.
Specifications:
| Tractor | Model | 151 |
| Power (hp) | 15 | |
| Dimensions(mm) | 2260×1030×1060 | |
| Wheel Tread(mm) | 640,680,740, 800 | |
| Ground Clearance(mm) | 210 | |
| Weight of chassis(kg) | 370 | |
| Gearbox | 6 Forward and 2 Reverse Gears | |
| Type of clutch | Double friction flat of constant combination | |
| Transmission | (3+1)*2combined cylindrical gear transmission | |
| Type of Steering | Joggling sleeve gear | |
| Type of brake | Internal Expanding Ring Type | |
| Type of tyre | 6.00-14 | |
| V belt | Type B 1880 | |
| Engine | Model | ZH1100 |
| Power(hp) | 15 | |
| Rated speed(r/min) | 2200 | |
| Type | Horizontal 4-stroke | |
| Cylinder bore(mm) | 100 | |
| Piston Stroke(mm) | 115 | |
| Cooling systerm | Water | |
| Starting mothod | Hand start |
