1BTSD Tande Disc Harrow
1BTSD Tande Disc Harrow,1 is used for ground breaking-up, soil lump smashing and crop residues mixing into soil as green manures. This series harrows perform excellently in small area that are difficult to harrow and with steep slopes.
online service
Product Description:
Technique parameter:
1BTSD Series Tandem Light Duty Disc Harrow, with compact structure design, is used for ground breaking-up, soil lump smashing and crop residues mixing into soil as green manures. This series harrows perform excellently in small area that are difficult to harrow and with steep slopes. Integrated harrow frame designing facilitates its structure firmness and using durability.
• 28×28 square harrow shaft used, 170mm spacing between discs
• High Carbon disc blade hardness: 38 - 44 HRC, assuring the toughness and wear ability of disc blade.
• Integrated harrow frame structure with reinforced tendons welded in it, more durable
• High harrowing speed and efficiency when three point mounted with tractor rear
• Especially performing well in rugged land with more steep slopes
• Disc harrow adopting using bearing combinations with a grease filling hole on it, keeping sand or soil from going into bearing to cause break-down and maintaining conveniently
• Excellent cross harrowing effect with tandem harrow frame designing
• High harrowing speed and efficiency when three point mounted with tractor rear
• Especially performing well in rugged land with more steep slopes
• Disc harrow adopting using bearing combinations with a grease filling hole on it, keeping sand or soil from going into bearing to cause break-down and maintaining conveniently
• Excellent cross harrowing effect with tandem harrow frame designing
|
Model
|
1BTSD-20
|
1BTSD-24
|
1BTSD-28
|
1BTSD-32
|
|
No. of disc
|
20
|
24
|
28
|
32
|
|
Disc diameter
|
18’’
|
18’’
|
18’’
|
18’’
|
|
Tractor power(hp)
|
40-50
|
50-60
|
60-70
|
70-80
|
|
Linkage
|
Standard three point mounted
|
|||
