TAY Heavy Hydraulic Disc Harrow
TAY Hydraulic offset heavy disc harrow is well suitable for heavy clay soil, waste land and weedy field as well,mainly suitable for stubble cleaning before farming
online service
TAY series Hydraulic offset heavy disc harrow is well suitable for heavy clay soil, waste land and weedy field as well,mainly suitable for stubble cleaning before farming , it can break the hardened soil and return the chopped straw to the soil, and also can crash the soil after tillage and level the land.The heavy-duty disc harrow can cultivate the soil instead of plow. This heavy disc harrow especially for the big farm field.
Advantages:
1. This hydraulic offset heavy disc harrow is trailed for 200-300hp tractor.
2. Own hydraulic system to lift and down the transport wheel freely.
3. High quality of difunctional oil cylinder.
4. Widely working width of this heavy disc harrow to be 5.0-6.5m
Advantages:
1. This hydraulic offset heavy disc harrow is trailed for 200-300hp tractor.
2. Own hydraulic system to lift and down the transport wheel freely.
3. High quality of difunctional oil cylinder.
4. Widely working width of this heavy disc harrow to be 5.0-6.5m
| Model | Unit | TAY4050 | TAY4455 | TAY4865 |
| Working width | mm | 5000 | 5500 | 6500 |
| Working depth | mm | 240 | 240 | 240 |
| Q’ty of disc | 40 | 44 | 48 | |
| Tyre specification | 10.00/75 | 7.50-16/11L-15 | 11L-15/400/60-15.5 | |
| Total weight | kg | 3900 | 4000 | 4300 |
| Matched power | hp | 200 | 260 | 300 |
| Linkage | Trailed(trailed hole diameter 38mm) ;hydraulic output 1 type(difunctional oil cylinder),oil connection in 1/2” thread | |||
