1LY(SX) Hydraulic Reversible Disc Plough
plastic water cup, Plastic Water Cup, Pig Water Cup, Hog Water Cup
online service
Product Description:
Technique parameter: • Two-way disc plough Hydraulic system is automatically and the operation is smooth without any troubles.
Hydraulic reversible two-way disc plough products are mainly used for tillage on dry cultivated or fallow land. They not only have the function of ordinary disc plough, but also have the characteristics of short idle distance of travel on the edge of fields, high productivity, low oil consumption etc. They are also suitable for working on terraced fields and small piece of farming land.
• When tillage,the two-way designing could reduce idling from both sides of the field.
| Model | unit | 1LY(SX)-325 | 1LY(SX)-425 | 1LY(SX)-525 | 1LY(SX)-625 |
| Working width | m | 0.75 | 1.0 | 1.25 | 1.5 |
| Working depth | cm | 25~30cm | 25~30cm | 25~30cm | 25~30cm |
| Q’ty of disc | 3 | 4 | 5 | 6 | |
| Diameter of disc | mm | 660 | 660 | 660 | 660 |
| Overall weight | kg | 620 | 700 | 830 | 950 |
| Matched power | hp | 50-80 | 80-100 | 100-120 | 120-150 |
| Linkage | Standard three point mounted | ||||
