1LYQ Rotary-Driven Disc Plough
1LYQ Rotary-Driven Disc Plough,1LYA Series paddy field disc plough is designed according to the feature of soil with moisture and more weeds in Southeast Asia ,especially suitable for cultivation in the land with more weeds and bricks.
online service
Product Description:
Technique parameter:• High Carbon disc blade hardness: 38-44 HRC, assuring the toughness and wear ability of disc blade
1LYQ series of rotary driven disc plough is mounted with tractor by the rear 3point suspension device and drives the plough discs to revolve in the way of delivering power by tractor's rear PTO to the disc plough’s gear box.This machine is mainly suitable for cultivation on paddy field with the advantages of non-tangling weeds,high quality and efficiency.
• Rotary driven disc plough can be forced to penetrate into the soil which is too hard and dry for working with a mouldboard
plough.
• 1LYQ rotary driven disc plough works well in sticky soil in which a mouldboard plough does not scour.
• A disc plough works well even after a considerable part of the disc is worn off in abrasive soil.
• Rotary driven disc plough works in loose soil also (such as peat) without much clogging.
| Model | unit | 1LYQ-422 | 1LYQ-522 | 1LYQ-622 | 1LYQ-722 | 1LYQ-822 |
| Working width | mm | 880 | 1100 | 1320 | 1540 | 1760 |
| Working depth | mm | 200-240 | 200-240 | 200-240 | 200-240 | 200-240 |
| Rotating speed of input shaft | r/min | 540/720 | 540/720 | 540/720 | 540/720 | 540/720 |
| Rotating speed of outer shaft | r/min | 90~120 | 90~120 | 90~120 | 90~120 | 90~120 |
| Matched power | hp | 18~22 | 25~30 | 40~50 | 50~60 | 60~70 |
| Overall weight | kg | 240 | 276 | 321 | 357 | 393 |
| Linkage | Standard three point mounted | |||||
