7C Double Axle Farm Trailer
Product Description: Double axle farm trailer included hydraulic tipping trailer and un-discharging trailer. It is producted in accordance with national standards. this tractor trailed trailer suitable for transporting in the farm land. Technique par
online service
• Max. load capacity – 10tons
• All side boards remove easily.
• With lights.
• Formed frame construction
• Expanded steel floor
• Powder-coated paint finish
• Strong and simple
Model | unit | 7C-3 | 7C-4 | 7C-5 | 7C-6 | 7C-7 | 7C-8 | 7C-9 | 7C-10 | |
Name | Four wheel trailer-double axle trailer | |||||||||
Capacity | Ton | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | |
Box size | m | 2x1x0.5 | 2.2x1.2x0.5 | 2.5x1.5x0.5 | 2.6x1.6x0.5 | 2.8x1.6x0.5 | 4.3x2x0.5 | 4.8x2x0.5 | 5.2x2x0.5 | |
Tyre | 750-16 | 750-16 | 825-16 | 825-16 | 900-20 | 900-20 | 900-20 | 900-20 | ||
Matched power | hp | 25-30 | 30-40 | 40-50 | 50-55 | 55-60 | 60-65 | 65-70 | 80-100 | |
Brake | Air brake | |||||||||
Linkage | Trailed |
