25HP Tractor
Agriculture tractor 25HP Tractor 1. 18hp,20hp,22hp,25hp,28hp,30hp,35hp compact tractor 2. Agriculture tractor ,lawn tractor,foton tractor,john deere tractor 3.Free logo printing
online service
iron crate or in bulk depends on tractor hp or as your request
Warmly remarks:
1. 18hp,20hp,22hp,25hp,28hp,30hp,35hp compact tractor
2. Agriculture tractor ,lawn tractor,foton tractor,john deere tractor
3.Free logo printing
4. Tractors prices good as used tractos
5.Tractor gearbox :8+2
6. Farm tractors made in china
7.Warranty time:18 months after delivery time
8.Tractor spare part:free tool box and easy wear parts
9.6/10 units in one 20ft container, 12 /20units in one 40ft container. SKD Iron Frame Package (Easy to Assembly in Destination)
10. With hot selling for tractor head ,tractor seat,cheap tractor tires,tractor battery,12.4-28 tractor tire
11.With implements:tractor grass cutter,tractor with front end loader and backhoe,tractor mower,tractor pto rotary tiller
12.We are tractor manufacture,our customers contains:tractor dealer,tractor wholesaler,farmer and so on
Warmly remarks:
1. 18hp,20hp,22hp,25hp,28hp,30hp,35hp compact tractor
2. Agriculture tractor ,lawn tractor,foton tractor,john deere tractor
3.Free logo printing
4. Tractors prices good as used tractos
5.Tractor gearbox :8+2
6. Farm tractors made in china
7.Warranty time:18 months after delivery time
8.Tractor spare part:free tool box and easy wear parts
9.6/10 units in one 20ft container, 12 /20units in one 40ft container. SKD Iron Frame Package (Easy to Assembly in Destination)
10. With hot selling for tractor head ,tractor seat,cheap tractor tires,tractor battery,12.4-28 tractor tire
11.With implements:tractor grass cutter,tractor with front end loader and backhoe,tractor mower,tractor pto rotary tiller
12.We are tractor manufacture,our customers contains:tractor dealer,tractor wholesaler,farmer and so on
| Model | 18HP | 20HP | 22HP | 25HP | 28HP | 30HP | 35HP | |||
| Engine | Rated powerKW) | 13.23 | 14.72 | 16.17 | 18.37 | 20.58 | 22.05 | 25..70 | ||
| model | JD290IT | JD290IT | JD295IT | JD2100IT | JD2102IT | JD2102IT | LD485 | |||
| (KN) Rated Traction | 4.7 | 6 | 6.5 | 7.2 | 7.2 | 7.4 | 7.6 | |||
|
(**) Overall Dimensions L*W*H (mm) |
2360 * 1200 * 1100 | |||||||||
| without suspension | ||||||||||
| wheel base(mm) | 1570 | 1590 | 1600 | |||||||
|
Tread (mm) |
Front Wheel | 1000 | ||||||||
| Rear Wheel | 960 | |||||||||
| Radius of Turining Circle(m) | One-side Braking | 2.3 | ||||||||
|
No Braking |
2.6 | |||||||||
| Clutch | dry,single stage,constant contract | |||||||||
| Gearbox | 3+1×24+1×2 (3+1)X2 or (4+1)X2 compound | |||||||||
| Final Drive | built-in, single straight spur gear | |||||||||
| Wheel Tyre |
Front Wheel Tyre |
4.00-12 for 2WD, 6.00-12 for 4WD | ||||||||
|
Rear Wheel Tyre |
9.50-16 | |||||||||
| Steering Type | , Front wheel steering,rear steeing trapezoid | |||||||||
| Steering Gear | Crank Stylus Pin Type | |||||||||
| Brake | Hoof Type | |||||||||
| Working Device |
PTO Shaft |
type | 35I6 Rear positioned, dependent, I 35 type, 6 teeth | |||||||
|
(R/min) Rated Speed |
540 / 540/720 or 540/1000Dual stage clutch * | |||||||||
