60HP Tractor
60HP Tractor, 600/604, 2WD, 4WD farm tractorwheel tractor tractor parts ,4 ,Turbo charger /Natural Aspirated
online service
| Model | 600/ 604 |
| Engine | |
| Engine Power KW/HP | 36,8 / 50 |
| Engine Type (Cyl, T/NA) | 4 ,Turbo charger /Natural Aspirated |
| Rated Speed (rpm) | 2400 |
| Engine Torque (Nm @ engine rpm) | 175~180,1600~1800 |
| Specific Fuel Consumption (L/h) | ≤10.9 |
| Emission Regulation availability (Euro I,II,II) | stageⅡ |
| Cooling type | Water cooling |
| Engine Displacement(L) | 3.168 |
| Air filter type | Oil Bath |
| Fuel tank capacity (litres) | 38 |
| Exhaust pipe (Vertical/Horizontal) | Vertical |
| Engine starter (kw) | 3.7 |
| Alternator (V/w) | 14V/500 |
| Transmission | |
| Type of clutch | Single, Dry |
| Total gears | 8 F + 4R |
| Synchronized Gearbox (YES/NO) | NO |
| Min-Max speed | 2.65-34 .78F / 3.94-12.1R |
| Differential lock (limited slip/100% lock) | 100% lock |
| Max Drawbar Pull 2WD/4WD (KN) | 13.5/18 |
| Type of rear final drive (PLanetary, cascade), | Planetary/3 |
| PTO | |
| Pto speeds PT(rpm) | 540 / 760 |
| PTO speed @ engine speed | 540/760,2400 |
| PTO engagement | 8XΦ38/6XΦ35/21XΦ35 |
| PTO independent clutch (YES/NO) | NO |
| PTO shaft splines | 6 or 8 |
| Hydraulic System | |
| Outlets pump type | gear pump |
| Max pressure (bar) | 175 |
| Max pump delivery @ engine rpm(ml/r),(rpm) | 16/2000 |
| Outlets valves function (Kick-out, Detent, Float) | Float |
| Technical Date | |
| Overall size 2WD (LxWxH) / mm | 3970x1640x2130 |
| Overall size 4WD (LxWxH) / mm | 3970x1640x2130 |
| Max height with ROPS | 2300 |
| Max height with CABIN / mm | 2500 |
| Rear Wheel track 2WD / mm | 1200-1500 |
| Front Wheel track 2WD / mm | 1200-1500 |
| Front Wheel track 4WD / mm | 1300 |
| Rear Wheel track 4WD / mm | 1200-1500 |
