Telescopic Wheel Loader
Telescopic wheel loader,telescopic wheel loader TL1500 with sand spreader, 1.5 ton mini backhoe loader for multi use,rear cover can be opened as a whole part just by your hands, which makes the maintenance much more simple
online service
telescopic loader
There are four models of HR series telescopic loader, HR1000, HR1500 and HR2500, lifting capacity from 1 ton to 2.5 tons, can meet customers’ different demands. Also based on our rich experiences with loaders, we can also design according to customers’ special requirement.
Features:
1.The telescopic boom which can reach 4.2m greatly increase it’s working scope.
2.The articulated structure and axle transmission design makes it powerful and has better pass through ability.
3.The seals, valve & joystick handle are famous oversea products which guarantee that it’s a reliable long lasting machine.
4.Adjustable aero seat and optional air conditioner makes the operating more comfortable.
5.Wide view cabin and two entrance makes the operating convenient and safe.
6.Quick coupling system, mechanic joystick and buttons makes the operating easy and convenient.
7.The rear cover can be opened as a whole part just by your hands, which makes the maintenance much more simple.
There are four models of HR series telescopic loader, HR1000, HR1500 and HR2500, lifting capacity from 1 ton to 2.5 tons, can meet customers’ different demands. Also based on our rich experiences with loaders, we can also design according to customers’ special requirement.
Features:
1.The telescopic boom which can reach 4.2m greatly increase it’s working scope.
2.The articulated structure and axle transmission design makes it powerful and has better pass through ability.
3.The seals, valve & joystick handle are famous oversea products which guarantee that it’s a reliable long lasting machine.
4.Adjustable aero seat and optional air conditioner makes the operating more comfortable.
5.Wide view cabin and two entrance makes the operating convenient and safe.
6.Quick coupling system, mechanic joystick and buttons makes the operating easy and convenient.
7.The rear cover can be opened as a whole part just by your hands, which makes the maintenance much more simple.
| Model | HR1000 | HR1500 | HR2500 |
| Engine model |
Xichai 490 with CE or Euro III Xinchai 498BPT |
Euro III Xinchai 498 | weichai 4102 |
| Engine power | 37/2400kw/r/min | 36.8/2400kw/r/min | 63/2400kw/r/min |
| Engine cooling way | Water cooling | Water cooling | Water cooling |
| Max. speed | 20 km/h | 22 km/h | 25 km/h |
| Transporting length | 4390 mm | 4460 mm | 4900 mm |
| Transporting height | 2720 mm | 2730 mm | 2740 mm |
| Transporting width | 1870 mm | 1880 mm | 1890 mm |
| Standard tire | 20.5-16 | 23.5-16 | 20.5/70-16 |
| Optional tire | 12-16.5 or 14-17.5 | 12-16.5 or 14-17.5 | 14-17.5 |
| Max. lifting capacity | 1000KG | 1500 kg | 2500 kg |
| Bukcet capacity | 0.6cbm | 0.7cbm | 0.8cbm |
| Bucket width | 1500mm | 1700mm | 1900mm |
| Max. height to the pin | 4200mm | 4200 mm | 4200 mm |
| Weight | 3900kg | 4100 kg | 5200 kg |
| Min turning radius | 4950mm | 4970mm | 5000mm |
| Wheelbase | 2400mm | 2450mm | 2500mm |
| Track | 1345mm | 1400mm | 1480mm |
| Braking type | Oil braking | Air braking | Air braking |
| Alxe | Without hub reducer | With hub reducer | With hub reducer |
