Skid Steer Loader
Skid Steer Loader, Skid Steer Wheel Loader,CE,ISO approved skid steer wheel loader for sale with CE&ISO,The telescopic boom which can reach 4.2m greatly increase its working scope
online service
Skid Steer Loader
Specification:
Specification:
| Model Item | THL380 | |||
| Engine | Rated Power(Kw) | 23Hp | ||
| Rotating speed(rpm) | 3600 | |||
| Noise (dB) |
 95 |
|||
| hydraulic System | Pressure(Mpa) | 17 | ||
| Cycle Time (s) | Raise | Dump | Lower | |
| 4.27 | 1.34 | 3.31 | ||
|
Performance |
Operating Load (Kg) | 200 | ||
| Bucket capacity (m3) | 0.15 | |||
| Max Lifting Force(Kg) | 375 | |||
| Speed (Km/h) | 0~5.5 | |||
| Operating weight(Kg) | 940 | |||
| Fuel tank(L) | 21 | |||
| Hydraulic oil tank(L) | 27 | |||
| Tyre | 16*6-8 | |||
| Max. height (mm) | 2112 | |||
| Dump height(mm) | 1460 | |||
| Overall height (mm) | 1205 | |||
| Overall length with bucket(mm) | 2206 | |||
| Dump distance (mm) | 388 | |||
| Overall Length without bucket(mm) | 1752 | |||
| Bucket width(mm) | 980 | |||
| Overall length to outside of tyre(mm) | 1033 | |||
| Ground clearance(mm) | 90 | |||
| Clearance circuit front (mm) | 1307 | |||
| Dump angle at max height |
30 |
|||
| Max attachment rollback when bucket on ground |
25 |
|||
