95HP Tractor
We supply a full line of farm tools. Different kind of tractors used in farm land, lawn,garden and different tractor implements. As a manufacturer we have the advantage to offer you the lowest price with highest performance ratio. We have full range o
online service
|
ractor model
|
950
|
||||
|
Tractor specifications
|
Type
|
4x2
|
|||
|
Rated traction(KN)
|
19.2
|
||||
|
Overall dimension
LxWxH(mm)
|
4225x2085x2925(with suspension)
|
||||
|
Wheel base(mm)
|
2195
|
||||
|
Tread
(mm)
|
Front wheel
|
1520(adjustable 1520-1820)
|
|||
|
Rear wheel
|
1620(adjustable 1620-2020)
|
||||
|
Min. ground clearance(mm)
|
370
|
||||
|
Min. turning radius(m)
|
4.3±0.2
|
||||
|
Weight(kg)
|
3474(with cab) or 3175(without cab)
|
||||
|
Design
Speed
(km/h)
|
Low-gear
|
2.31-8.03(normal)/0.46-1.61(with creeper-gear)
|
|||
|
High-gear
|
10.04-34.85(normal)/2.01-6.97(with creeper-gear)
|
||||
|
Reverse-gear
|
3.10-10.78(normal)/0.62-2.16(with creeper-gear)
|
||||
|
Engine
|
Model
|
LRC4108T61X
|
|||
|
Rated power(kw)
|
69.86
|
||||
|
Rated speed(r/min)
|
2300
|
||||
|
Fuel consumption
(g/kw.h)
|
≤242.00
|
||||
|
Oil consumption
(g/kw.h)
|
≤1.63
|
||||
|
Transmission
|
Type of transfer gerabox
|
Spur gear shift
|
|||
|
Clutch
|
Single-leaf,dry,dual-action,butterfly style pressed spring,separately operated clutch
|
||||
|
Gearbox
|
Composed type,4x(2+1)x2spur gear shift(with creeper-gear)
|
||||
|
Cnetral transmission
|
Spiral bevel gear
|
||||
|
Differential
|
Closed,4planetary bevel gear
|
||||
|
Front differential
|
Closed,2planetary bevel gear
|
||||
|
Differential lock
|
Mesh sleeve type
|
||||
|
Front final transmission
|
Single planetary bevel gear
|
||||
|
Rear final transmission
|
|||||
|
Walking&
steering
|
Tyre
|
Front tyre
|
6.5-20
|
||
|
Rear tyre
|
16.9-34
|
||||
|
13.6-38(paddy type)
|
|||||
|
Steering type
|
Independent mode,full hydraulic front wheel steering
|
||||
|
Steering gear
|
Full hydraulic steering gear
|
||||
|
Working device
|
PTO shaft
|
Type
|
Rear-positioned,independent type,35 rectangle splines,6gears
|
||
|
Rated speed(r/min)
|
540/1000(can choose 760/1000)
|
||||
|
Max pulling force(hung at the 610mm point in the rear)
|
>15KN
|
||||
1.Multi-way valve
2.Airbrake
