1 Ton Wheel Loader
1 Ton Wheel Loader， diesel forklift wheel loader ZL10F CE,4 WD Wheel Loader,1T Wheel Loader,Optional Attachments and Colors,4-wheel drive and fully hydraulic steering system
online service
Features of china wheel loader with quick coupler:
*ultra-wide tyres to increase the stability of loader
*4-wheel drive and fully hydraulic steering system
*can be equipped with many optional devices by quick coupler
*ultra-wide tyres to increase the stability of loader
*4-wheel drive and fully hydraulic steering system
*can be equipped with many optional devices by quick coupler
| Item | ZL10A Parameters | ZL10F Parameters |
| 1 .Rated Load | 1000 kg | 1000 kg |
| 2. Total Weight | 2500 kg | 2530 kg |
| 3. Rated Bucket Capacity | 0.5 m3 | 0.5 m3 |
| 4. Max. Tractive Force | 30KN | 30 KN |
| 5. Max. Breakout Force | ≥ 30 KN | ≥ 30 KN |
| 6. Max. Gradeability | 38° | 38° |
| 7. Dumping Height | 2800 mm | 2800 mm |
| 8. Dumping Reach | 980 mm | 980 mm |
| 9. Raising Time | ≤ 4.5 s | ≤ 4.5 s |
| 10. Total Cycle Time | ≤ 8.5 s | ≤ 8.5 s |
| 11. Overall Dimensions (L x W x H) | 4800*1650*2550 mm | 4800*1650*2600 mm |
| 12. Min. Turning Radius | 3000 mm | 3000 mm |
| 13. Model | CHANGCHAI 385 | CHANGCHAI 485/XINCHAI 490 |
| 14. Type | Two-cylinder, Horizontal,Water- cooled Evaporative, Four-stroke Engine | Four-cylinder, Inline, Water-cooled, Four-stroke Engine |
| 15. Rated Power | 20 kw | 36.8 kw |
| 16. Rated Speed | 2200 rpm | 2200 rpm |
| 17. Min. Fuel Consumption Ratio | ≤215 g/kw·h | ≤ 215 g/kw·h |
| 18. Model | Mechanical Shift | Mechanical Shift |
| 19. Gear Shift | 3 Forward, 1 Reverse | 3 Forward, 1 Reverse |
| 20. Max. Speed | 25 km/h | 25 km/h |
| 21. Model | 50 Drive Axle | 50 Axle |
| 22. Wheel Tread | 1370 mm | 1370 mm |
| 23. Wheel Base | 2150 mm | 2150 mm |
| 24. System Working Pressure | 16 Pa | 16 Pa |
| 25. Fuel Tank Capacity | 70L | 70 L |
| 26. Driving Brake | Drum Brake | Foot Drum Brake |
| 27. Parking Brake | Flexible Shaft Controlled Disc Brake | Hand Flexible Shaft Controlled Disc Brake |
| 28. Type Specification | 1200-16 | 1200-16 |
| 29. Front Tyre Pressure | 0.40 Mpa | 0.40 Mpa |
| 30. Rear Tyre Pressure | 0.35 Mpa | 0.35 Mpa |
