5 Ton Wheel Loader
5 Ton Wheel Loader Multiple purpose small loader CE,5000kg loader Construction loader for sale,ZL50 wheel loader/log grapple
online service
1.Multiple purpose small loader CE
2.5000kg loader Construction loader for sale
3.ZL50 wheel loader/log grapple
2.5000kg loader Construction loader for sale
3.ZL50 wheel loader/log grapple
| Model: ZL50F | ||
| Item | Parameters | |
| Performance |
|
5000kg |
|
17100kg | |
| 3. Rated Bucket Capacity | 3.0m3 | |
|
152KN | |
|
≥170KN | |
|
30° | |
|
3150mm | |
|
1250mm | |
|
7920*3050*3400mm | |
|
6640mm | |
| Engine |
|
WEICHAI STEYR WD615G220/Cummins 6CTAA8.3-C215 |
|
In-line, Water Cooling, Dry Cylinder, Fuel Injection 4-stroke, Water Cooling, Injection, Turbocharged |
|
| 13. No. of Cylinder-Bore/Stroke | 6-126×130mm/6-114x135mm | |
|
162 kW – 2400rpm/160 kW--2200r/min | |
|
860N·m/980N.m | |
|
≤215g/kW·h | |
| Transmission System |
|
YJ375 |
|
Planetary | |
|
2 Forward Shift, 1 Reverse Shift | |
|
38km/h | |
| Drive Axle |
|
Bevel Gear Grade 1 Reduction |
|
Planetary Reduction Grade 1 | |
|
2250mm | |
|
3200mm | |
|
450mm | |
| Hydraulic System | 26. System Working Pressure | 18MPa |
| 27. Boom Raising Time | 5.95s ± 0.2s | |
| 28. Total Cycle Time | 10.95s ± 0.5s | |
| 29. Fuel Tank Capacity | 300L | |
| 30. Automatic Release Function | Yes | |
| Brake system | 31. Service Brake | Air Over Hydraulic Disc Brake on 4 Wheels |
| 32. Parking Brake | Manual Ring-hub Brake | |
| Tyre | 33. Type Specification | 23.5-25 |
| 34. Front Tyre Pressure | 0.4Mpa | |
| 35. Rear Tyre Pressure | 0.35Mpa | |
